TIMING INDEX BELOW - SKIP AROUND! :) GRAB HEADPHONES YOU'LL APPRECIATE WHAT THIS DOING EASIER ... pinky promise.

Here's the very excellent, very underrated, very overlooked LRMSMSLR module from WORNG Electronics ... that's wrong, spelt wrong ...

The LRMSMSLR takes a stereo input (left and right) then sums them together to create a mid input and creates a signal that's a difference of the two to create a side signal. This is a common mastering technique often doing things such as removing low end from the side stereo elements to clean up a mix. The mid signal is a single mono channel and the side input is a single mono channel, it's the way their phases are flipped and interacting when brought back together to recreate a stereo image. It's great for taking that side output and using mono FX modules that when brought back into the module create stereo images with those FX on them from super wide to more subtle stereo images (with a dry unprocessed mid to keep things focused). It can also do some unity summing, CV difference / averaging. Lots of patches, lots to get through, skip through the index below if you can't watch all the way through.

TIMING INDEX

00:00 Hello and patch previews of what’s to come.

01:03 Verbal feature walk through, what is mid/side? Patch suggestions and WORNG’s patch examples from the manual.

DUAL DETUNED OSCILLATOR PATCHES (mono FX modules turned stereo)

3:33 Two separate oscillators with detune waves into the left and right. Using manual control on a VCA to show mid and side signals and how that affects stereo image.

05:33 Processing the side channel through a phaser (XAOC Kamieniec)

06:40 Processing the side channel through a pitch shifting delay (Make Noise / Soundhack - Echophon)

07:29 Distortion over the mid channel (Metasonix R51)

08:14 Distorted mids and phaser modulation sides

08:36 Side signal through a reverb (AJH Synth Finaliser R-EQ) with the addition of some pitch sequencing.

09:36 Stereo sideband creator - Stereo Ring Modulation FX (AJH Synth Ring SM)

12:43 Using a VCA to modulate stereo width.

SEVERAL EXAMPLES OF STEREO AUDIO PROCESSING

13:39 Modern cutting/bright synth riff. Showing the mid/side elements and processing the side with FX that “as if by magic” now appear in stereo.

15:59 Ambient piano. Stereo piano, resonator, reverb stereo signal. Splitting into mid/side and processing through a phaser.

17:02 Acoustic drum loop. Using the side signal as a way to pull out and/or remove the room reverb around the drum kit. Then processed through an Echophon, frozen and mangled.

18:04 Dirty, gritty bass wub-wubs. Side signal reverb added.

UTILTIES

18:58 Mixing the left and right signals from two mono sources (to left and to right) and taking the mid output as a summed output.

19:53 Using the mid and side inputs with two different CV signals as a “cv averager”.

21:07 Using two mono signals into the left and right and using the mid as a summed CV and the side as a CV difference both modulating independent VCAs for relating but different modulation signals.

USING TWO DIFFERENT FILTERS (even stereo image without matched filters)

22:47 The last patch uses two different filters over the mid and side and two different modulation signals of them. This creates a stereo filtering effect even though I don’t have two of the same filters to get a matched / even stereo image. This also means filtering them differently creates a moving stereo image/width. Very cool.

25:21 Mega end video schpeal - how do you even spell that? - get your mum and dog to like the video then go support me on Patreon :)

MODULES USED IN THIS VIDEO

AJH Synth Finaliser R-EQ - https://youtu.be/naTKF60KcRs

AJH Synth Ring SM - https://youtu.be/FvMfFl9vY14

Befaco Hexmix - https://youtu.be/wbT2nMRZbgM

Befaco Rampage - https://youtu.be/drDfZAkVi4k

Make Noise Echophon - https://youtu.be/rODmNS76KHg

Metasonix Tube Modules - https://youtu.be/JRc0VlththQ

Mordax DATA - https://youtu.be/W2HIsrTBwt4

XAOC Kamieniec - https://youtu.be/JRsnaZ9596I
